Round steel induction heating furnace

ound steel induction heating furnace application range

It is suitable for the overall heating of round steel, square steel, bar and other workpieces below Φ120mm.

The main parameters:

Model SD-500/2

Power supply: three-phase four-wire 380V   50-60Hz

Input power: 500KW

IF range : 2KHZ-3KHZ

Duty ratio : 100%

Input current: 750 A

Dimensions: 1200 × 760 × 2060mm

Features:

1. Use IGBT devices and components for global procurement.

2. Adopt high efficiency combined resonance technology.

3. Low-inductance circuit arrangement and large-scale digital circuit.

4. Adopt more comprehensive and mature protection technology.

Random Accessories:

One set of main control cabinet, one furnace, and pneumatic feeding (optional items: closed cooling tower and infrared thermometer)

Production beat: The output is 1250 KG per hour and the power consumption is 320-360 KWH/T per ton .
